X-ray Flaw Detection

Applicable materials: Suitable for dense metal materials such as carbon steel, alloy steel, stainless steel, aluminum alloy, copper alloy, titanium alloy, as well as some non-metallic materials with qualified density.

Applicable objects: including welded joints, castings, forgings, plates, pipes, pressure vessels, industrial pipelines, steel structures, aerospace components, and other internal defect detection workpieces.

Applicable scenarios: Used for internal volume defect detection of workpieces, product manufacturing quality acceptance, regular inspection of in-service equipment, non-destructive testing judgment, and defect level assessment.

Internal defect detection: detection of defects such as porosity, slag inclusion, shrinkage, porosity, incomplete penetration, incomplete fusion, cracks, looseness, inclusions, segregation, etc.

Defect parameter determination: evaluation of defect location, shape, size, distribution status, and equivalent size.

Verification of transmission process: Verification of transmission direction, focal length, voltage, current, exposure time, and rationality of film/imaging board selection.

Sensitivity verification: Use an image quality indicator to verify contrast, clarity, and sensitivity.

Record and determine the nature, location, and size of defects.

Defect acceptance level assessment, testing result recording, and report preparation.
