Rubber Sheet Testing
Universal rubber sheet: natural rubber sheet, chloroprene rubber sheet, nitrile rubber sheet, styrene butadiene rubber sheet, ethylene propylene rubber sheet.
- Fast Delievery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Detection range
(1) Material type
Universal rubber sheet: natural rubber sheet, chloroprene rubber sheet, nitrile rubber sheet, styrene butadiene rubber sheet, ethylene propylene rubber sheet
Special rubber sheets: silicone rubber sheet, fluororubber sheet, conductive/anti-static rubber sheet, insulating rubber sheet, oil resistant rubber sheet, acid alkali resistant rubber sheet, flame-retardant rubber sheet, food grade rubber sheet
Composite/modified rubber sheet: laminated rubber sheet, foamed rubber sheet, recycled rubber sheet, rubber composite sheet
(2) Product Form
Board: Industrial rubber sheet, insulation rubber sheet, anti slip rubber sheet, sealing rubber sheet, shock-absorbing rubber sheet, lining rubber sheet
Products: Rubber flooring, rubber floor tiles, track pads, bridge support pads, mechanical sealing pads, chemical anti-corrosion pads
(3) Application scenarios
Industrial fields: mechanical manufacturing, chemical anti-corrosion, electrical insulation, mining anti-skid, petroleum oil resistance, equipment sealing
Construction field: Ground paving, shock absorption and isolation, waterproof sealing, pipeline lining
Transportation field: rail transit pads, automotive parts, ship seals, bridge supports
Special environments: high temperature conditions, low temperature conditions, ozone environment, acid-base media, food contact, conductive/anti-static places
Testing items
(1) Basic physical performance
Appearance and Dimensions: Surface Quality, Thickness Deviation, Width/Length Tolerance, Flatness, Edge Quality
Density: Determination of unit volume mass by drainage method
Hardness: Shore A/D hardness, International Rubber Hardness (IRHD)
Resilience: rebound rate test to evaluate the ability of elastic recovery
Water absorption rate: rate of change in mass after immersion in water
Volatile matter/ash content: thermal stability and impurity content detection
(2) Mechanical properties
Tensile properties: tensile strength, elongation at break, tensile stress
Tear performance: Right angle/crescent tear strength
Compression performance: permanent compression deformation, compression strength
Impact performance: low-temperature/room temperature impact embrittlement, impact resistance
Wear resistance: Akron wear, DIN wear, Taber wear
Fatigue performance: dynamic fatigue life, repeated compression/tensile durability
Adhesive performance: peel strength and pull-out strength with fabric/metal substrate
(3) Environmental aging resistance performance
Hot air aging: retention rate of tensile strength/elongation after high-temperature aging
Ozone aging: static/dynamic stretching ozone exposure, assessment of cracking level
Weather resistant aging: Xenon lamp/UV aging, detecting loss of light, discoloration, powdering, and cracking
Low temperature performance: brittleness temperature, low temperature bending/compression performance
Moisture and heat resistance: Performance stability under high temperature and high humidity environments
(4) Chemical resistance performance
Oil resistance: volume/hardness/mass change rate after soaking in standard oil
Acid and alkali resistance: changes in performance and swelling rate after soaking in acidic and alkaline solutions
Solvent resistance: swelling, dissolution, and performance degradation after soaking in organic solvents
(5) Special functional performance
Electrical insulation performance: breakdown voltage, volume resistivity, surface resistivity, dielectric constant
Conductive/anti-static performance: surface resistance, volume resistance, electrostatic decay time
Flame retardant performance: oxygen index, vertical combustion grade, smoke density, toxicity index
Food contact safety: heavy metals, migration amount, odor, microbial indicators
Anti slip performance: static/dynamic friction coefficient, anti slip grade evaluation
Testing Standards
GB/T 5574-2008 Rubber sheets for industrial use
GB/T 528-2009 Determination of tensile stress-strain properties of vulcanized rubber or thermoplastic rubber
GB/T 529-2008 Determination of Tear Strength of Vulcanized Rubber or Thermoplastic Rubber
GB/T 531.1-2008 Rubber, vulcanized or thermoplastic - Test method for indentation hardness
GB/T 7762-2014 Rubber, vulcanized or thermoplastic - Static tensile test method for resistance to ozone aging
GB/T 1689-2014 Determination of Wear Resistance of Vulcanized Rubber
GB/T 1690-2010 Test Method for Liquid Resistance of Vulcanized Rubber or Thermoplastic Rubber
GB/T 15256-2014 Determination of low-temperature brittleness of vulcanized rubber or thermoplastic rubber
GB 11176-2021 Electrical Insulation Rubber Sheet
GB/T 30680-2014 General Technical Conditions for Fluororubber Plates
GB/T 3985-2008 Asbestos Rubber Sheet
GB/T 539-2008 Oil resistant asbestos rubber sheet
ISO 34-1:2015 Determination of Tear Strength of Vulcanized Rubber or Thermoplastic Rubber
ISO 188:2011 Rubber, vulcanized or thermoplastic - Accelerated aging and heat resistance tests in hot air
ISO 815-1:2019 Determination of compression set of vulcanized rubber or thermoplastic rubber
ISO 1433-1:2019 Rubber, vulcanized or thermoplastic, resistant to ozone aging
ISO 1817:2022 Test Method for Liquid Resistance of Vulcanized Rubber or Thermoplastic Rubber
ASTM D412-16 Tensile Test Method for Vulcanized Rubber, Thermoplastic Rubber, and Elastomers
ASTM D471-16a Rubber Properties - Standard Test Method for Liquid Effects
ASTM D2240-21 Rubber Characteristics - Standard Test Method for Shore Hardness Tester Hardness
