Gear Inspection

Applicable materials: Suitable for various gear specific materials such as high-quality carbon structural steel, alloy structural steel, stainless steel, cast iron, powder metallurgy, copper alloy, etc.

Applicable products: including cylindrical gears, bevel gears, worm gears, spur gears, helical gears, herringbone gears, planetary gears, transmission gears, engineering machinery gears, precision transmission gears, and various types of gear shafts.

Applicable scenarios: Used for raw material incoming inspection, heat treatment quality assessment, processing accuracy acceptance, assembly meshing performance testing, in-service equipment monitoring, failure analysis, and quality arbitration testing.

Chemical composition analysis: determination of alloy element content such as carbon, silicon, manganese, sulfur, phosphorus, chromium, nickel, molybdenum, manganese, etc., and determination of material grade and composition conformity.
Mechanical performance testing: surface hardness, core hardness, quenching layer depth, carburizing layer depth, tensile strength, impact toughness, contact fatigue strength, bending fatigue strength testing.
Gear accuracy testing: cumulative tooth pitch deviation, individual tooth pitch deviation, tooth profile deviation, helix deviation, radial runout, end face runout, gear accuracy grade evaluation.
Dimensional and positional tolerance testing: accuracy evaluation of outer diameter, inner diameter, tooth width, keyway size, hole position, coaxiality, perpendicularity, parallelism, symmetry, etc.
Surface quality inspection: Inspection of appearance defects such as surface roughness, tooth surface bumps, scratches, burns, cracks, peeling, pitting, and wear marks.
Metallographic structure testing: inspection of quenched and tempered structure, carburized layer structure, grain size, non-metallic inclusions, decarburization layer, and banded structure.
Non destructive testing: magnetic particle inspection, penetrant inspection, ultrasonic inspection, used for detecting defects such as cracks, inclusions, and looseness on tooth surfaces and inside.
Mesh and assembly performance testing: evaluation of gear mesh clearance, contact spots, operating noise, vibration, and transmission stability.
Failure analysis: Analysis of failure modes and causes such as gear tooth breakage, fatigue pitting, wear, bonding, plastic deformation, corrosion, and fracture.
