Ceramic Testing

Ceramic Testing

Ceramic materials are a type of inorganic non-metallic materials made by shaping and high-temperature sintering natural or synthetic compounds. They have the advantages of high melting point, high hardness, high wear resistance, and resistance to oxidation. They can be used as structural materials, cutting tool materials, and due to their certain special properties, they can also be used as functional materials. Different testing institutions may have different focuses on the items and standards for ceramic testing. Here, we will take Keji Testing as an example to introduce the main testing items and standards for ceramic testing. The inorganic testing center of Keji has rich experience in testing ceramic materials: including ceramic density, ceramic whiteness, ceramic composition, and ceramic fire resistance testing, etc.

Testing Products



By application: daily-use ceramics, building ceramics, sanitary ceramics, industrial ceramics, etc.;

By composition: oxide ceramics, nitride ceramics, carbide ceramics, metal ceramics, etc.; special ceramic materials: structural ceramics, cutting tool ceramics, functional ceramics;

Specific material classification: alumina ceramics, silicon nitride ceramics, silicon carbide ceramics, hexagonal boron nitride ceramics; diamond, hard alloy, cubic boron nitride; dielectric ceramics, optical ceramics, magnetic ceramics, semiconductor ceramics.

Physical properties: Gloss, whiteness, appearance quality, specification size, radiation performance, size and surface quality, tensile modulus and breaking strength;

Mechanical properties: Stiffness, hardness, toughness, plasticity, compressive strength;

Thermal properties: Thermal conductivity, expansion coefficient, chemical stability, dimensional stability;

Electrical properties: Conductivity, breakdown voltage or breakdown strength, insulation resistance, dielectric constant; Chemical properties: Resistance to acid and alkali, corrosion resistance, oxidation resistance, etc.;

Chemical composition: Element content, oxide content.

GB/T 3302-82 Rules for Acceptance, Packaging, Marking, Transportation and Storage of Daily-use Ceramic Ware

GB/T 11423-89 Technical Conditions for Paper Box Packaging of Daily-use Ceramics

GB/T 23561.1-2009 Test Methods for Properties of Ceramic Materials - Part 1 - Density and apparent porosity

GB/T 6569-2006 Test Method for Bending Strength of Fine Ceramics

GB/T 23806-2009 Test Method for Fracture Toughness of Fine Ceramics

GB/T 4340.1-2009 Test Method for Vickers Hardness of Metallic Materials - Part 1 - Test Procedure

GB/T 8489-2006 Test Method for Compressive Strength of Ceramics

GB/T 16535-2008 Test Method for Linear Thermal Expansion Coefficient of Fine Ceramics

GB/T 22588-2008 Test Method for Thermal Diffusivity of Fine Ceramics (Laser Flash Method)

GB/T 1410-2006 Test Method for Volume Resistivity and Surface Resistivity of Solid Insulating Materials

GB/T 5597-2019 Test Method for Dielectric Properties of Fine Ceramics

GB/T 16927.1-2011 High Voltage Test Technology - Part 1 - General Definitions and Test Requirements

GB/T 1970-2008 Test Method for Chemical Resistance of Ceramics

GB 4806.4-2016 Food Safety National Standard - Ceramic Products

Zhejiang Gangxin Testing Technology Co., Ltd.

was established in 2011. As a national high-tech enterprise recognized by the Zhejiang Provincial Higher People's Court as a judicial authentication institution for construction engineering quality, we specialize in structural performance testing and safety assessment of construction projects, special equipment, communication towers, electromagnetic environments, large bridges, and building safety appraisal.

The company has more than 100 professional and technical personnel, over 90% of whom hold various medium and senior technical certificates. Equipped with complete testing equipment worth over RMB 10 million, our business scope covers the whole country.
